Specification
Crucible capacity* :        184 cc.  (1151 g sterling, 1439 g. 14 k.)
Over all dimension :        35 x 22 x 38 inch  (89 x 56 x 97 cm.)
Power requirements :      200-240V., 45A., Single-Phase 50/60 Hz.
Perf. Flask capacity :      5 x 9 inch  (127 x 229 mm.)
Normal cycle time :         4  minutes
Max. temperature :         2750 ºF/1510 ºC
Weight :                         290 lbs./132 kg.
Shipping weight :            410 lbs./186 kg.

* Working capacity—60% of liquid capacity using casting grain.
